Tech specs
Brand
Palo Alto Networks
Product Line
Palo Alto Networks
Model
PA-5250
Manufacturer
Palo Alto Networks
Hard Drive Capacity
240 GB
Hard Drive Capacity (2nd)
2 TB
Port Expansion Hard Drive Type
SSD
Storage (2nd)
HDD
Compliant Standards
IEEE 802.1Q, IEEE 802.1x, IEEE 802.3ad (LACP)
Connectivity Technology
Wired
Data Link Protocols
10 Gigabit Ethernet, 100 Gigabit Ethernet, 40 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Features
Anti-malware protection, Anti-spyware protection, Antivirus analysis, Content filtering, DDos attack prevention, DHCP server, DHCP support, DiffServ support, DoS attack prevention, High Availability, IPv4 support, IPv6 support, LDAP support, Manageable, NAT support, Quality of Service (QoS), Syslog support, VLAN support, Web threat protection
Form Factor
Rack-mountable
Network Standard
DHCP, PPPoE
Product Type
Security appliance
Routing Protocol
BGP, Bidirectional Forwarding Detection (BFD), IGMP, IGMPv2, IGMPv3, OSPFv2, OSPFv3, PIM-SM, PIM-SSM, Policy-based routing (PBR), RIP, Static IP routing
Interface Provided
1 x 100Gb Ethernet (management) - QSFP28, 1 x console - RJ-45, 16 x 10Gb Ethernet - SFP+, 3 x 1000Base-T (management) - RJ-45, 4 x 100Gb Ethernet - QSFP28, 4 x 10Gb Ethernet - RJ-45
Frequency
50/60 hertz
Power Consumption Operational
870 watt
Power Provided
1200 watt
Power Supplies Installed
2
Power Supplies Supported
2
Redundant Power Supply
Yes
Operating System Edition
PAN-OS
Built-in Devices
LED panel
Encryption
128-bit AES, 192-bit AES, 256-bit AES, 256-bit SHA, 384-bit SHA-2, 512-bit SHA-2, IKE, IKEv2, MD5, SHA-1, SSL, Triple DES
Max Operating Temperature
50 degree Celsius
Min Operating Temperature
0 degree Celsius
MTBF
9.23 Year
Capacity
Maximum number of sessions: 8000000, New sessions per second: 384000, Virtual systems: 25
Device Type
Internal power supply
Packaged Quantity
1
Network Device
Firewall throughput: 35.9 Gbps, Threat prevention throughput: 20.3 Gbps, VPN throughput (IPSec): 14 Gbps
Height
13.3 centimetre
Height (Rack Units)
3
Weight
20.87 kilogram
Width
43.81 centimetre
Depth
52.07 centimetre
Color Category
Black, Blue
Compliant Standards
CB, cCSAus, FCC Class A certified, IEC 60950-1, VCCI Class A ITE
