Tech specs
Brand
Cisco
Product Line
Cisco Catalyst
Model
9300
Edition
Network Essentials
Manufacturer
Cisco Systems
Flash Memory Installed
16 GB
RAM Installed
8 GB
Compliant Standards
IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3u, IEEE 802.3x
Features
16MB packet buffer, 3 fans, 802.1x authentication, Access Control List (ACL) support, Cisco StackPower technology, Cisco StackWise-480 technology, Control plane protection (CoPP), Flexible NetFlow (FNF), FTP client, Full duplex mode, Integrated Wireshark, Management Information Base (MIB), Private VLAN, Quality of Service (QoS), Remote Switch Port Analyzer (RSPAN), Source-Specific Multicast (SSM), Spanning Tree Protocol (STP) support, Trunking, VLAN Double Tagging (Q-in-Q), Weighted Random Early Detection (WRED)
Form Factor (Hubs & Switches)
Rack-mountable
Jumbo Frame Support
9198 bytes
MAC Address Table Size
32000 entries
Manageable
Yes
Ports
24
Product Type
Switch
Remote Management
CLI, NETCONF, RESTCONF, RMON 1, RMON 2, SNMP 1, SNMP 2c, SNMP 3
Routing Protocol
IGMP, IS-IS, OSPF, OSPFv3, PIM-SM, PIM-SSM, Policy-based routing (PBR), RIP-1, RIP-2, RIPng, VRRP
Stackable
Stackable
Status Indicators
Status
Subcategory
Network hubs and switches
Switching Type
Gigabit Ethernet
Expansion Slots
1 (total) / 1 (free) x expansion slot
Interface Provided
1 x USB 2.0, 48 x 1000Base-T RJ-45
Port Quantity
24
Port Type
10/100/1000
Frequency
50 - 60 hertz
Hot-Plug
Hot-plug
Power Provided
350 watt
Power Supplies Installed
1
Power Supplies Supported
2
Redundant Power Supply
Optional
Encryption
128-bit AES
Humidity Range Storage
5 - 90% (non-condensing)
Max Operating Temperature
45 degree Celsius
Max Storage Temperature
70 degree Celsius
Min Operating Temperature
-5 degree Celsius
Min Storage Temperature
-40 degree Celsius
MTBF
314,790 Hours
Operating Humidity
5 - 90% (non-condensing)
Operating System Required
Cisco IOS Universal
Capacity
Flexible NetFlow entries: 64000, IPv4 routing table entries: 32000, IPv6 routing table entries: 16000, Switched virtual interfaces (SVIs): 2000, VLAN IDs: 4000
Device Type
Internal power supply
Packaged Quantity
1
Performance
Forwarding rate: 154.76 Mpps, Stacking bandwidth: 480 Gbps, Switching capacity: 128 Gbps
Height
4.4 centimetre
Height (Rack Units)
1
Weight
7.27 kilogram
Width
44.5 centimetre
Depth
44.5 centimetre
Color Category
Gray
Compliant Standards
AS/NZS 3548 Class A, BSMI Class A, CAN/CSA-C22.2 No. 60950-1, CCC, CISPR 22 Class A, CISPR 24, EN 300 386, EN 55022 Class A, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-6-1, EN50082-1, EN55024, FCC CFR47 Part 15 A, ICES-003 Class A, IEC 60950-1, RoHS 5/6, TVCN 7317, UL 60950-1, VCCI Class A, VCCI V-3/2009 Class A
ENERGY STAR Certified
No
Service & Support Details
Limited warranty - replacement - lifetime - response time: next business day, Technical support - consulting - 90 days
Limited Warranty
Limited Lifetime
