Tech specs
Brand
Cisco
Product Line
Cisco Industrial Ethernet
Model
2000 Series
Manufacturer
Cisco Systems
Flash Memory Installed
64 megabyte
RAM Installed
256 megabyte
Compliant Standards
IEEE 802.1x
Features
Broadcast Storm Control, DHCP support, Multicast Storm Control, Port Security, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, Remote Switch Port Analyzer (RSPAN), Spanning Tree Protocol (STP) support, Unicast Storm Control
Form Factor (Hubs & Switches)
DIN rail mountable
MAC Address Table Size
8K entries
Manageable
Yes
Ports
4
Product Type
Switch
Remote Management
HTTPS, SNMP 3, SSH
Routing Protocol
IGMP, Static IPv4 routing
Subcategory
Network hubs and switches
Switching Type
Fast Ethernet
Expansion Slots
1 (total) / 1 (free) x SD Memory Card
Interface Provided
2 x SFP (mini-GBIC), 4 x 100Base-TX RJ-45
Port Quantity
4
Port Type
10/100
Ports Type (2nd)
Gigabit SFP
Software Type
Cisco IOS LAN Base
Max Storage Temperature
85 degree Celsius
Min Storage Temperature
-40 degree Celsius
MTBF
374,052 Hours
Operating Humidity
5 - 95% (non-condensing)
Authentication Method
RADIUS, Secure Shell (SSH), TACACS+
Capacity
Virtual interfaces (VLANs): 255
Packaged Quantity
1
Performance
Forwarding performance (64-byte packet size): 6.5 Mpps
Ports (2nd) Quantity
2
Rack Mounting Kit
Optional
Height
12.7 centimetre
Weight
1.11 kilogram
Width
7.37 centimetre
Depth
11.46 centimetre
Compliant Standards
CISPR 11, CISPR 22 Class A, CISPR 24, CSA 22.2 No. 142, C-Tick, EN 60950-1, EN 61000-4-2, EN 61000-4-29, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-9, EN 61000-6-1, EN 61000-6-4, EN 61131-2, EN 61326-1, EN55022 Class A, FCC CFR47 Part 15, FCC Part 15 A, ICES-003 Class A, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-30, IEC 60068-2-6, IEC 60529 IP30, IEC 60950-1, IEC 61000-4-11, KCC, RoHS, UL 508, UL 60950-1, VCCI Class A ITE
Service & Support Details
Limited warranty - 1 year
Limited Warranty
1 Year
