Tech specs
Brand
Seasonic
Product Line
Seasonic VERTEX
Model
PX-750
Manufacturer
Seasonic Electronics Inc
Cooling System
135 mm fan
Emergency Power Off
Fluid dynamic bearing cooling fan, Fully modular, Gold-plated terminals, Overcurrent protection, Overheat protection, Overpower protection, Overvoltage protection, Premium Hybrid Fan Control, Short-circuit protection, Undervoltage protection
Frequency
50 - 60 hertz
Output Current
+12V - 62 A, +3.3V - 20 A, +5V - 20 A, +5VSB - 3 A, -12V - 0.3 A
Power Output Connectors Details
1 x 12VHPWR, 1 x power 24 pin ATX with detachable 4 pin section, 18 x 15 pin Serial ATA power, 2 x 8 pin PCI Express power with detachable 2 pin section, 2 x power 8 pin +12V with detachable 4 pin section, 3 x 4 pin internal power
Power Provided
750 watt
Power Supply Compatibility
PC/Server
Provided Voltage
+3.3, +5, ±12 volt
PSU Form Factor
ATX
Required Voltage
AC 100-240 volt
Specification Compliance
ATX12V
80 PLUS Certification
80 PLUS Platinum
Efficiency
92% at 50% Load
Form Factor (Power Device)
Internal
Max Operating Temperature
50 degree Celsius
Min Operating Temperature
0 degree Celsius
Modular
Yes
MTBF
150,000 Hours
Packaged Quantity
1
Product Type
Power Supply
Subcategory
Power supplies
Included Accessories
Cable bag, Cable ties, Case badge, PSU tester
Height
8.6 centimetre
Width
15 centimetre
Depth
16 centimetre
Color Category
Black
Compliant Standards
BSMI, CB, CCC, cTUVus, EAC, Energy-Related Products (ErP) Lot 6, REACH, RoHS, TUV, WEEE
Energy Star
Yes
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 10 years
Limited Warranty
10 Year
