Tech specs
Brand
Lenovo
Product Line
Lenovo ThinkCentre M80q Gen 4
Model
12E9
Manufacturer
Lenovo
Clock Speed
1.6 GHZ
Cores
14-core
Max Turbo Speed
4.6 GHZ
Platform Technology
Intel vPro Enterprise
Processor Brand
Intel
Processor Generation
13
Processor Number
i5-13500T
Processor Type
Core i5
Processors Installed
1
Total Processor Supported
1
Available Memory Slots
1
Cache Memory Installed
24 megabyte
Configuration Features
1 x 16 GB
Features
Dual channel memory architecture
Max Memory Supported
64 GB
Memory Slots
2
Memory Speed
4800 megahertz
Memory Technology
DDR5 SDRAM
RAM Installed
16 GB
Rated Memory Speed
4800 megahertz
Drive Interface
PCI Express 4.0 x4
Drive Type
No optical drive
Hard Drive Capacity
512 GB
Hard Drive Features
NVM Express (NVMe), TCG Opal Encryption 2
Installed Quantity
1
Interface Class
PCI Express
Optical Drive Type
No optical drive, None
Optical Drive Type (2nd)
None
SSD Form Factor
M.2 2280
Storage (2nd)
None
Storage (3rd)
None
Storage (4th)
None
Storage Controller Type
Serial ATA
Type
None
Hard Drive Interface Type
SSD
Display Technology
None.
Graphics Controller Model
Intel UHD Graphics 770
Graphics Processor Series
Intel UHD Graphics
Maximum Monitors Supported
4
Video Interfaces
DisplayPort, HDMI
Audio Input Type
None
Compliant Standards
High Definition Audio
Memory Allocation Technology
Shared video memory (UMA)
Interface Provided
1 x DisplayPort 1.4a, 1 x HDMI (1 rear), 1 x headphones/microphone (1 in front), 1 x LAN (Gigabit Ethernet) (1 rear), 1 x USB 3.2 Gen 1 (1 rear), 1 x USB 3.2 Gen 1 (1 rear) (supports SmartPower On), 1 x USB 3.2 Gen 2 (1 in front) (Always On, fast-charging (5V, 2.1A)), 1 x USB-C 3.2 Gen 2, 2 x DisplayPort, 3 x USB 3.2 Gen 2 (1 front, 2 rear)
Data Link Protocols
Bluetooth 5.3, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet Controllers
Intel I219-LM
Features
Dual stream (2x2), Wake On LAN (WOL)
Host Interface
M.2 Card
Wireless LAN
802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth 5.3
Wireless LAN Supported
Yes
Wireless NIC
Intel Wi-Fi 6E AX 211
Built-in Devices
Speaker
Chipset Type
Intel Q670
Efficiency
89%
Embedded Security
Discrete Trusted Platform Module (TPM 2.0) Security Chip
Form Factor
Ultra Small Form Factor
Form Factor (RAM)
SO-DIMM 262-pin
Storage Controller Interface
Serial ATA-600
Input Device Type
Keyboard, Mouse
Interface
USB
Max Operating Temperature
35 degree Celsius
Min Operating Temperature
5 degree Celsius
Mouse Name
Lenovo Calliope Mouse
Operating Humidity
20 - 80%
Controllers Included
1
Country
United States
Printer Product Type
None
Keyboard Localization
English
Keyboard Name
Lenovo Traditional Keyboard
Keys Layout
QWERTY
Localization
English
Manufacturer Form Factor
Tiny
Packaged Quantity
1
Product Type
Personal computer
Security Slot Type
Kensington security slot
Theft Protection
Chassis intrusion switch, Security lock slot (cable lock sold separately)
Slots
1 (total) / 0 (free) x M.2 Card (for WLAN), 2 (total) / 1 (free) x M.2 Card (for SSD)
Operating System
Windows 11 Pro
Operating System Edition
Windows 11 Pro
Operating System Language
English
Operating System Platform
Windows
Frequency
50/60 hertz
Power Device Type
Power adapter
Power Provided
90 watt
Required Voltage
AC 100-240 volt
Included Accessories
Vertical stand
Color
Black
Color Category
Black
Height
3.65 centimetre
Weight
1.25 kilogram
Width
17.9 centimetre
Depth
18.29 centimetre
Compliant Standards
Energy-Related Products (ErP) Lot 3, FIPS 140-2, RoHS, TCG Certified, TCO Certified 9.0
ENERGY STAR Certified
Yes
Energy Star Version
8.0
EPEAT Compliant
Yes
EPEAT Level
EPEAT Silver
TCO Certified
No
On-Site Warranty
On-site
Service & Support Details
Limited warranty - 3 years - on-site
Limited Warranty
3 Year
