Tech specs
Brand
HPE
Product Line
HPE ProLiant
Model
DL380 Gen10
Manufacturer
HPE BTO Server & Accessories
Clock Speed
2.1 GHZ
Cores
8-core
Max Turbo Speed
3.2 GHZ
Processor Brand
Intel
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology
Processor Number
4208
Processor Type
Xeon Silver
Processors Installed
1
Server Scalability
2-way
Total Processor Supported
2
Upgradability
Upgradable
Available Memory Slots
10
Cache Memory
L3 cache
Cache Memory Installed
11 megabyte
Configuration Features
2 x 32 GB
Features
HPE SmartMemory, Registered, Slots 13 - 24 are available in two-processor configuration only
Flash Memory Cards Supported
microSD
Max Memory Supported
1.5 TB
Memory Card Reader
Card reader
Memory Slots
12
Memory Speed
2400 megahertz
Memory Supported
1.5 TB registered - ECC, 192 GB Non-Volatile - ECC, 3 TB Load-Reduced - ECC
Memory Technology
DDR4 SDRAM
RAM Installed
64 GB
Rated Memory Speed
2933 megahertz
Buffer Size
2 GB
Channel Quantity
8
Drive Type
No optical drive
Hard Drive Capacity
480 GB
Installed Quantity
2
Interface Class
Serial ATA
Optical Drive Type
No optical drive, None
Optical Drive Type (2nd)
None
SSD Form Factor
2.5"
Storage (2nd)
None
Storage (3rd)
None
Storage (4th)
None
Storage Controller (2nd)
None
Storage Controller Name
HPE Smart Array P408i-a SR Gen10
Storage Controller Type
RAID
Type
None
Hard Drive Interface Type
SSD
Data Link Protocols
Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet Ports
4 x Gigabit Ethernet
Features
PXE support, Wake On LAN (WOL)
Remote Management
IPMI 2.0, SMASH CLP, SNMP 3
Remote Management Controller
Integrated Lights-Out 5
Expansion Bays
1 (total) / 1 (free) x external Universal Media Bay, 8 (total) / 6 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x FlexibleLOM, 1 (total) / 1 (free) x microSD Card (internal), 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height, 2 (total) / 2 (free) x PCIe 3.0 x8 - half-length, full-height
Interface Provided
1 x HPE iLO - RJ-45 (1 rear), 1 x HPE iLO - Type A (1 in front), 1 x VGA (1 rear), 4 x LAN (Gigabit Ethernet) - RJ-45 (4 rear), 5 x USB 3.0 (1 front, 2 rear, 2 internal)
Display Technology
None.
Video Interfaces
VGA
Installed Size
16 megabyte
Frequency
50/60 hertz
Power Device Type
Power supply - hot-plug
Power Provided
800 watt
Power Supplies Installed
2
Power Supplies Supported
2
Redundant Power Supply
Optional
Redundant Power Supply Supported
1+1 (with optional power supply)
Required Voltage
AC 100-240 volt
80 PLUS Certification
80 PLUS Platinum
Software Type
HPE Server UEFI
Built-in Devices
LED panel
Chipset Type
Intel C621
Embedded Security
Trusted Platform Module (TPM) Security Chip
Form Factor
Rack-mountable
Form Factor (RAM)
DIMM 288-pin
Storage Controller Interface
Serial Attached SCSI 3
Max Operating Temperature
35 degree Celsius
Min Operating Temperature
10 degree Celsius
Operating Humidity
8 - 90% (non-condensing)
Controllers Included
1
Country
Canada, United States
Printer Product Type
None
Hot-Swap Bays
8
Manufacturer Form Factor
Rack-mountable
Packaged Quantity
1
Product Type
Server
Server Storage Bays
Hot-swap
Server Swappable Drive Form Factor
2.5"
Server Swappable Drive Form Factor (metric)
6.4 cm
Server Swappable Drive Interface
SATA/SAS
Included Accessories
4 standard fans
Height
8.74 centimetre
Height (Rack Units)
2
Weight
14.76 kilogram
Width
44.55 centimetre
Depth
73.03 centimetre
Color Category
Black, Silver
Compliant Standards
ACPI 6.3, AES, ASHRAE Class A3, ASHRAE Class A4, FIPS 140-2, Redfish API, SMBIOS 3.2, TLS v1.2, Triple DES, UEFI, WEEE
ENERGY STAR Certified
Yes
TCO Certified
No
On-Site Warranty
On-site
Service & Support Details
Limited warranty - parts and labor - 3 years - on-site - response time: next business day
Limited Warranty
3 Year
