Tech specs
Brand
Ericsson
Product Line
Ericsson Cradlepoint
Model
S400
Manufacturer
Cradle Point
Processor Brand
ARM
Broadband Transmission Technology
2.4 GHz / 5 GHz
Cellular Data Connectivity Technology
5G NR, FDD LTE, TDD LTE
Compliant Standards
IEEE 802.11k, IEEE 802.11v, Wi-Fi CERTIFIED
Connectivity Technology
Wired, Wireless
Data Link Protocols
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Features
2x2 MIMO technology, 3GPP Release 11, eSIM support, GPS/GLONASS/Galileo/BeiDou support, Plastic housing, Reset button, Security slot (Kensington security lock compatible)
Form Factor (Hubs & Switches)
Desktop
Key Features
Firewall, USB port, VPN support
Product Type
Wireless router
WAN Ports Quantity
1
Wireless LAN
802.11a/b/g/n/ac
Modem Transmission Data Rate
150 MBps
Expansion Slots
1 expansion slot, 2 (total) / 2 (free) x Nano-SIM
Interface Provided
Antenna: 1 x RP-SMA - Wi-Fi, Antenna: 2 x SMA - LTE, USB 2.0: 1 x 4 pin USB Type A, WAN / LAN: 2 x 10Base-T/100Base-TX/1000Base-T (PoE) - RJ-45
Bundled Services
3 years NetCloud IoT Essentials Plan
Power Consumption Operational
13 watt
Required Voltage
DC 2.9 - 3.15 volt
Antenna Form Factor
External detachable
Antennas
3
Built-in Devices
GNSS receiver, GPS / GLONASS / Galileo
Encryption
WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal, WPA-Personal
Internet of Things (IoT) Compatible
Yes
Line Coding Format
16 QAM
Max Operating Temperature
70 degree Celsius
Min Operating Temperature
-30 degree Celsius
MTBF
1,407,191 Hours
Operating Humidity
10 - 90%
Capacity
Concurrent TCP sessions: 32000, Concurrent VPN tunnels: 20, Layer 2 VLANs: up to 64, Typical client count: 50
Country
Global
Device Type
External power adapter
IoT Communications Technology
5G, LTE Cat 6
Packaged Quantity
1
Product Type
Wireless cellular modem
Service Activation
No
Bridge & Router
Maximum data rate (2.4 GHz): 574 Mbps, Maximum data rate (5 GHz): 1.2 Gbps, Stateful firewall throughput: 95 Mbps, VPN throughput (IPSec): 20 Mbps
Included Accessories
Antennas, Power supply
Height
4.1 centimetre
Weight
601 gram
Width
13.36 centimetre
Depth
12.15 centimetre
Color Category
Black
Compliant Standards
ANATEL, ATEX Zone 2, CB Scheme, Class 1 Div 2 (C1D2), CP65, EN 62368-1, FCC, FCC Part 96, IC, IEEE 802.3af Class 3, IFT, IMDA, IP30, IP64, MCMC, MIL-STD-810H 514.8, MIL-STD-810H 516.8, NMEA, PTCRB, RCM, REACH, RoHS, Subtel, TAIP, UKCA, UL/cUL, WEEE
Service & Support Details
Limited warranty - lifetime
Limited Warranty
Limited Lifetime
Compatibility Specs
P/N: 170716-001, 170717-000, 170864-000, 170873-000
