Tech specs
Brand
Datamax-O'Neil
Product Line
Datamax M-Class Mark II
Model
M-4206
Manufacturer
Datamax
Flash Memory Installed
8 megabyte
Flash Memory Size
8 megabyte
RAM Installed
16 megabyte
Product Type
Print server
Interface
LAN, Parallel, Serial, USB 2.0, Wi-Fi
Interface Required Connections
1 x LAN - RJ-45, 1 x parallel - 36 pin Centronics, 1 x RS-232 - 9 pin D-Sub (DB-9), 1 x USB 2.0 - 4 pin USB Type B
Fonts
CG Triumvirate, OCR-A, OCR-B
Max B/W Print Resolution
203 dpi
Max H-Document Size
118.1 mm
Max Mono Print Speed
152
Max Print Length
2514.6 millimetre
Max Print Size
Roll (11.8 cm)
Max Roll Diameter
203 millimetre
Maximum Print Width
108 millimetre
Media Thickness Range
0.064 mm - 0.254 mm
Min H-Document Size
19 mm
Print Output Type
Monochrome
Print Speed
Up to 152 mm/sec - max speed - 203 dpi
Wireless Print Technology
Wired, Wireless
Wireless Print Technology Ready
Yes
Barcode Symbology Supported
Aztec code, Codabar, Code 128, Code 3 of 9, Code 93, Data Matrix, EAN/JAN-13, EAN/JAN-8, FIM, GS1 DataBar, HIBCC, Interleaved 2 of 5, MaxiCode, MicroPDF417, PDF417, Plessey, Postnet, QR code, Telepen, TLC39, UCC/EAN-128, UPC, UPC-A, UPC-E
Media Feeders
1 x manual - 1 roll - Roll (11.81 cm)
Media Size Class
Other
Media Sizes
Roll (1.9 - 11.8 cm)
Media Type
Other
Frequency
50/60 hertz
Nominal Voltage
AC 110 V
Power Device Type
Power supply
Software Type
Drivers & Utilities
Power Device Form Factor
Internal
Display Graphic Resolution
128 x 64
Max Operating Temperature
35 degree Celsius
Media Type
Continuous forms, Fanfold paper, Labels, Perforated labels, Perforated tags, Tag stock, Tickets
Min Operating Temperature
4 degree Celsius
Operating System Required
Microsoft Windows NT, Microsoft Windows Vista / XP
Printer Label Keys
5
Roll Core Diameter
38 mm, 76.2 mm
Built-in Devices
Peeler, Status LCD
Country
United States
Label Printer Features
Peeler, Rewinder
Office Machine Type
Printer
Printer Product Type
Label printer
Scanner Functionality
None
Printer Functions
Printer
Packaged Quantity
1
Print Technology
Direct thermal
Text Styles
Mirror
Height
25.9 centimetre
Weight
12.2 kilogram
Width
25.7 centimetre
Depth
46.2 centimetre
