Tech specs
Brand
Cisco
Product Line
Cisco
Model
819 Non-Hardened 4G LTE ISR
Manufacturer
Cisco Systems
Flash Memory Installed
1 GB
Max Flash Memory Supported
1 GB
Max Memory Supported
1 GB
RAM Installed
1 GB
Cellular Data Connectivity Technology
CDMA 2000 1X EV-DO Rev. A, LTE
Compliant Standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x
Connectivity Technology
Wired
Data Link Protocols
Ethernet, Fast Ethernet
Features
Access Control List (ACL) support, Auto-uplink (auto MDI/MDI-X), Class of Service (CoS), Class-Based Weighted Fair Queuing (CBWFQ), Content filtering, DHCP client, DHCP relay, DHCP server, DiffServ Code Point (DSCP) support, DiffServ support, DNS proxy, Dynamic Multipoint VPN (DMVPN), Firewall protection, Firmware upgradable, IGMP snooping, Intrusion Prevention System (IPS), IPv6 support, Link Fragmentation and Interleaving (LFI), Low-latency queuing (LLQ), MAC address filtering, NAT support, Quality of Service (QoS), RADIUS support, Spanning Tree Protocol (STP) support, Virtual Route Forwarding-Lite (VRF-Lite), VLAN support, VPN support, Weighted Fair Queuing (WFQ)
Form Factor (Hubs & Switches)
Desktop
Integrated Switch
4-port switch
Key Features
Firewall, USB port, VPN support
Network Standard
IPSec
Product Type
Router
Remote Management
CLI, HTTP, SNMP 3, SSH, Telnet
Routing Protocol
BGP, Bidirectional Forwarding Detection (BFD), EIGRP, GRE, HSRP, NHRP, OSPF, Policy-based routing (PBR), RIP-1, RIP-2, WCCP
Status Indicators
Active, System, Wireless
WAN Ports Quantity
1
Modem Transmission Data Rate
100 MBps
Expansion Slots
2 (total) / 2 (free) x SIM
Interface Provided
LAN: 4 x 10Base-T/100Base-TX - RJ-45, Management: 1 x RJ-45, USB: 1 x mini-USB Type A, WAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45
Frequency
50/60 hertz
Operating System
Cisco IOS Advanced IP services
Antenna Form Factor
External detachable
Antennas
2
Encryption
128-bit AES, 192-bit AES, 256-bit AES, DES, PKI, Triple DES
Max Operating Temperature
50 degree Celsius
Min Operating Temperature
-10 degree Celsius
MTBF
605,000 Hours
Authentication Method
RADIUS, TACACS+
Capacity
IPSec VPN tunnels: 20
Device Type
External power adapter
Packaged Quantity
1
Product Type
Wireless cellular modem
Service Activation
No
Height
4.2 centimetre
Weight
1 kilogram
Width
19.6 centimetre
Depth
18.3 centimetre
Color Category
Gray
Compliant Standards
BSMI CNS 13438, CISPR 22, CISPR 24, CSA C22.2 No. 60950-1 Second Edition, EN 300 386, EN 301 489-1, EN 301 489-24, EN 301 489-7, EN 301 511, EN 301 908, EN 60950-1 Second Edition, EN 61000-3-2, EN 61000-3-3, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-6-1, EN55022, EN55024, FCC CFR47 Part 15, ICES-003, IEC 60950-1 Second Edition, UL 60950-1 Second Edition, VCCI V-3
Service & Support Details
Limited warranty - 1 year
Service Provider
Verizon Wireless
Limited Warranty
1-year warranty
