Tech specs
Brand
ASUS
Product Line
ASUS
Model
RT-AXE7800
Manufacturer
Asus
Clock Speed
1.7 GHZ
Processors Installed
1
Flash Memory Installed
256 megabyte
RAM Installed
512 megabyte
Broadband Transmission Technology
2.4 GHz / 5 GHz / 6 GHz
Connectivity Technology
Wired, Wireless
Data Link Protocols
2.5 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Data Transfer Rate
7800 MBps
Features
160MHz bandwidth support, 3G/4G USB Dongle Support, Adaptive QoS, AiMesh node mode, Airtime Fairness, Android tethering, ASUS AiCloud, ASUS AiDisk, ASUS AiMesh, ASUS AiProtection, ASUS AiProtection Pro, ASUS Instant Guard, ASUSWRT, Auto firmware update, Bandwidth Limiter, Bandwidth Monitor, Beamforming technology, DDNS (Dynamic Domain Name Service), DHCP server, DMZ support, Dual WAN connection, Explicit Beamforming, External HDD hibernation, FTP server, Guest Network, H.323 Pass-Through, IPSec passthrough, IPSec VPN server, IPTV support, IPv6 support, L2TP passthrough, L2TP VPN client, Let's Encrypt, Link Aggregation, Login captcha, MAC address filtering, Malicious Site Blocker, MU-MIMO technology, NAT passthrough, OpenVPN client, OpenVPN server, Orthogonal Frequency Division Multiple Access (OFDMA), Parental control, Port forwarding, Port triggering, PPPoE relay, PPTP VPN client, PPTP VPN server, Quad-core CPU, RADIUS support, Reset button, RTSP Pass-Through, Samba support, Shared folder permission, SIP Pass-Through, SSH support, System log, Traffic Analyzer, Traffic monitoring, Tri-Band, URL filtering, VPN Fusion, Wake On LAN (WOL), Wireless Scheduler, WPS button
Form Factor (Hubs & Switches)
Desktop
Integrated Switch
4-port switch
Key Features
Firewall, USB port, VPN support
Network Standard
IPSec, L2TP, PPPoE, PPTP, RTSP
Product Type
Wireless router
Status Indicators
2.4 GHz, 5 GHz, 6 GHz, LAN, Power, WAN
WAN Ports Quantity
2
Wi-Fi Rating
AX7800
Wireless LAN
802.11a/b/g/n/ac/ax (Wi-Fi 6E)
Interface Provided
LAN: 3 x 10Base-T/100Base-TX/1000Base-T - RJ-45, USB 3.2 Gen 1: 1 x 9 pin USB Type A, WAN / LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45, WAN / LAN: 1 x 2.5GBase-T - RJ-45
Frequency
50/60 hertz
Required Voltage
AC 110-240 volt
Antenna Form Factor
External
Antennas
6
Encryption
WPA2-Enterprise, WPA2-Personal, WPA3-Personal, WPA-Enterprise, WPA-Personal, WPS
Internet of Things (IoT) Compatible
Yes
Max Operating Temperature
40 degree Celsius
Min Operating Temperature
0 degree Celsius
Operating Humidity
50 - 90%
Virtual Assistant Supported
Alexa
Capacity
Firewall keyword filters: 64, Firewall network service filters: 32, Firewall URL filters: 64, MAC filter entries: 64, QoS rules/classes: 32
Device Type
External power adapter
Packaged Quantity
1
Service Activation
No
Bridge & Router
Maximum data rate (2.4 GHz): 574 Mbps, Maximum data rate (5 GHz): 4804 Mbps, Maximum data rate (6 GHz): 2402 Mbps
Cables
1 x network cable
Weight
1.03 kilogram
Color Category
Black
Compliant Standards
FCC Part 15 Class B, REACH
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
