Tech specs
Brand
HPE
Product Line
HPE OfficeConnect
Model
1420 8G
Manufacturer
HP Networking
Flash Memory Installed
1.5 megabyte
Flash Memory Size
1.5 megabyte
Compliant Standards
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Features
Auto-negotiation, Auto-uplink (auto MDI/MDI-X), DiffServ Code Point (DSCP) support, Fanless, Flow control, Full duplex capability, Half duplex mode, Quality of Service (QoS)
Form Factor (Hubs & Switches)
Desktop
MAC Address Table Size
4096 entries
Manageable
No
Ports
8
Product Type
Switch
Subcategory
Network hubs and switches
Switching Type
Gigabit Ethernet
Interface Provided
8 x 1000Base-T RJ-45
Port Quantity
8
Port Type
10/100/1000
Frequency
50/60 hertz
Nominal Voltage
AC 120/230 V
Power Consumption Operational
4.5 watt
Humidity Range Storage
15 - 95% (non-condensing)
Max Operating Temperature
40 degree Celsius
Max Storage Temperature
70 degree Celsius
Min Operating Temperature
0 degree Celsius
Min Storage Temperature
-40 degree Celsius
Operating Humidity
15 - 95% (non-condensing)
Country
United States
Device Type
Internal power supply
Localization
English
Packaged Quantity
1
Performance
Latency (100 Mbps): 3 µs, Latency (1000Base-T): 2.6 µs, Switching capacity: 16 Gbps, Throughput (64-byte packet size): 11.8 Mpps
Height
2.69 centimetre
Weight
500 gram
Width
15.77 centimetre
Depth
10.49 centimetre
Color Category
Gray, White
Compliant Standards
CAN/CSA C22.2 No. 60950-1-03, CISPR 22, CISPR 24, EN 60950-1, EN55022, EN55024, FCC Part 15 B Class A, IEC 60950-1, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, Plug and Play, UL 60950
Service & Support Details
Limited warranty - lifetime
Limited Warranty
Limited lifetime warranty
