Tech specs
Brand
Fortinet
Product Line
Fortinet FortiGate
Model
60F
Manufacturer
Fortinet
Processor Brand
Fortinet
Processor Type
FortiASIC SOC4
Processors Installed
1
Connectivity Technology
Wired
Data Link Protocols
10 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Features
Antivirus analysis, Fanless, Firewall protection, Intrusion Prevention System (IPS), IPSec Virtual Private Network (VPN), Web threat protection
Form Factor
Desktop
Network Standard
IPSec
Product Type
Security appliance
Interface Provided
1 x console - RJ-45, 1 x USB 3.0 - Type A, 2 x 1000Base-T - RJ-45, 2 x 1000Base-T - RJ-45 (WAN / DMZ), 5 x 1000Base-T - RJ-45
Bundled Services
1 year FortiCare Premium Support + 1 year FortiGuard Enterprise Protection
Frequency
50/60 hertz
Power Consumption Operational
10.17 watt
Power Supplies Installed
1
Encryption
SSL, TLS 1.3
Max Operating Temperature
40 degree Celsius
Min Operating Temperature
0 degree Celsius
Operating Humidity
10 - 90% (non-condensing)
Capacity
Client to gateway IPSec VPN tunnels: 500, Concurrent sessions: 700000, Concurrent SSL VPN users: 200, Firewall policies: 5000, Gateway to gateway IPSec VPN Tunnels: 200, Latency: 3.3 µs, Maximum number of FortiTokens: 500, New sessions: 35000, Number of FortiAP devices (tunnel mode): 32, Number of FortiAP devices: 64, Number of FortiSwitches: 24, Number of registered FortiClients: 200, SSL inspection concurrent sessions: 55000, SSL inspection CPS: 400, Virtual domains: 10
Device Type
External power adapter
Packaged Quantity
1
Service Activation
No
Network Device
Application control (AVC) throughput: 1.8 Gbps, CAPWAP Throughput (HTTP 64K): 8 Gbps, Firewall throughput (1518-byte UDP): 10 Gbps, Firewall throughput (512-byte UDP): 10 Gbps, Firewall throughput (64-byte UDP): 6 Gbps, Firewall throughput: 9 Mpps, Firewall throughput: 9000000 packets per second, IPS throughput: 1.4 Gbps, Maximum data rate (2.4 GHz): 450 Mpps, Maximum data rate (5 GHz): 1300 Mbps, NGFW throughput: 1 Gbps, SSL inspection throughput: 630 Mbps, Threat protection throughput: 700 Mbps, VPN throughput (512-bit IPSec): 6.5 Gbps, VPN throughput (SSL): 900 Mbps
Height
3.9 centimetre
Weight
1.01 kilogram
Width
21.6 centimetre
Depth
16 centimetre
Color Category
White
Compliant Standards
BSMI, CB, cUL, FCC, ICES, RCM, UL, VCCI
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
