Tech specs
Brand
Cisco
Product Line
Cisco ONE ISR
Model
4221
Manufacturer
Cisco Systems
Flash Memory Installed
8 GB
Max Flash Memory Supported
8 GB
Max Memory Supported
4 GB
Memory Technology
DDR3 SDRAM
RAM Installed
4 GB
Compliant Standards
ANSI T1.101, IEEE 802.1ag, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ah, ITU-T G.823, ITU-T G.824
Connectivity Technology
Wired
Data Link Protocols
Ethernet, Fast Ethernet, Gigabit Ethernet
Features
Access Control List (ACL) support, Class-Based Weighted Fair Queuing (CBWFQ), IPFIX, IPv6 support, NetFlow, Quality of Service (QoS), RADIUS support, Syslog support, VLAN support, VPN support, Wall mountable, Weighted Random Early Detection (WRED)
Form Factor (Hubs & Switches)
Rack-mountable
Key Features
USB port, VPN support
Modular
Modular
Network Standard
DHCP, IPSec, PPPoE
Product Type
Router
Remote Management
RMON, SNMP
Routing Protocol
BGP, DVMRP, EIGRP, GRE, IGMPv3, IPv4-to-IPv6 Multicast, IS-IS, OSPF, PIM-SM, PIM-SSM, Policy-based routing (PBR), RIP-1, RIP-2, Static IPv4 routing, Static IPv6 routing
WAN Ports Quantity
2
Expansion Slots
2 (total) / 2 (free) x NIM
Interface Provided
1 x SFP (mini-GBIC), Management: 1 x 1000Base-T - RJ-45, Serial: 1 x console - RJ-45, USB 2.0: 1 x 4 pin USB Type A, WAN / LAN: 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45
Frequency
50/60 hertz
Operating System
Cisco IOS IP Base
Max Operating Temperature
40 degree Celsius
Min Operating Temperature
0 degree Celsius
MTBF
593270 Hours
Operating Humidity
5 - 85%
Device Type
External power adapter
Packaged Quantity
1
Rack Mounting Kit
Included
Service Activation
No
Bridge & Router
Aggregate throughput: 35 Mbps
Height
4.37 centimetre
Height (Rack Units)
1
Weight
3.22 kilogram
Width
32.26 centimetre
Depth
25.4 centimetre
Color Category
Black
Compliant Standards
AS/NZS 3548 Class A, AS/NZS 60950-1, CAN/CSA-C22.2 No. 60950-1, CISPR 22 Class A, CISPR 24, CNS 13438, CS-03, EN 300 386, EN 60950-1, EN 61000, EN50082-1, EN55022 Class A, EN55024, FCC CFR47 Part 15, GB 4943, ICES-003 Class A, IEC 60950-1, KN22, KN24, R&TTE, UL 60950-1, VCCI V-3
