Tech specs
Brand
VMware
Product Line
VMware SD-WAN Edge
Model
3800, Capex
Manufacturer
Vmware
RAM Installed
32 GB
Hard Drive Capacity
256 GB
Port Expansion Hard Drive Type
SSD
Installed Quantity
1
Compliant Standards
IEEE 802.1ad, IEEE 802.1Q, IEEE 802.1x
Connectivity Technology
Wired
Data Link Protocols
10 Gigabit Ethernet, Gigabit Ethernet
Features
3G/4G USB Dongle Support, DHCP client, DHCP relay, DHCP server, High Availability, Link Aggregation, MAC address filtering, NAT support, NetFlow, Port forwarding, Quality of Service (QoS), RADIUS support, Routing, Syslog support, VLAN Tagging
Form Factor
Rack-mountable
Product Type
Application accelerator
Remote Management
SNMP
Routing Protocol
BGP, OSPF, Static IP routing
Interface Provided
1 x console - mini-USB, 1 x console - RJ-45, 2 x USB 3.0, 4 x 10GBase-X - SFP+ (WAN / LAN), 6 x 1000Base-T - RJ-45 (WAN / LAN)
Frequency
50/60 hertz
Hot-Plug
Hot-plug
Power Consumption Operational
200 watt
Power Supplies Installed
2
Power Supplies Supported
2
Redundant Power Supply
Yes
Encryption
128-bit AES, 256-bit AES, IKEv2, PKI, SHA-1, SHA-2, TLS 1.2
Max Operating Temperature
45 degree Celsius
Min Operating Temperature
0 degree Celsius
MTBF
17.1 Year
Operating Humidity
5 - 85%
Capacity
Flows per second: 19200, Maximum concurrent flows: 3800000, Maximum number of routes: 100000, Maximum segments: 16, Tunnel scale: 6000
Device Type
Internal power supply
Packaged Quantity
1
Pricing Units
1 edge
Network Device
Internet traffic (IMIX): 5 Gbps, Maximum throughput (1300-byte packet size): 10 Gbps, Throughput (64-byte packet size): 1 Gbps
Height
4.4 centimetre
Height (Rack Units)
1
Weight
7.14 kilogram
Width
43.4 centimetre
Depth
38.1 centimetre
Color Category
Black
Compliant Standards
AS/NZ 3548 Class A, AS/NZS 60950-1, CAN/CSA-C22.2 No. 60950-1, CISPR 22 Class A, CISPR 24, CNS 13438, EN 300 386, EN 55022 Class A, EN 60950-1, EN 61000, EN50082-1, EN55024, FCC CFR47 Part 15, GB 4943, ICES-003 Class A, IEC 60950-1, UL 60950-1, VCCI V-3
Service & Support Details
Extended service agreement - replacement - 1 year - response time: next day
Limited Warranty
1 Year
