Tech specs
Brand
Synology
Product Line
Synology Disk Station
Model
DS423+
Manufacturer
Synology
Clock Speed
2 GHZ
Cores
Quad-Core
Max Turbo Speed
2.7 GHZ
Processor Brand
Intel
Processor Number
J4125
Processor Type
Celeron
Processors Installed
1
Total Processor Supported
1
Max Memory Supported
6 GB
Memory Technology
DDR4 SDRAM
RAM Installed
2 GB
iSCSI support
iSCSI
Max Supported Capacity
108 TB
Network Storage Type
NAS server
Optical Drive Type
None
RAID Levels
JBOD, RAID 0, RAID 1, RAID 10, RAID 5, RAID 6
Total Storage Capacity
0 GB
Type
RAID
Compliant Standards
DLNA CERTIFIED
Data Link Protocols
Ethernet, Fast Ethernet, Gigabit Ethernet
Features
Access Control List (ACL) support, High Availability, NFS Kerberos authentication, OpenStack compatible, RAID migration, SSD read-write cache, SSD trim, VPN Server, Wake On LAN (WOL)
Host Connectivity (compact list)
Gigabit Ethernet
Network Services Compatibility
Apple File Protocol (AFP), Calendaring Extensions to WebDAV (CalDAV), FTP, Network File System v3 (NFS v3), Network File System v4 (NFS v4), Network File System v4.1 (NFS v4.1), Server Message Block (SMB), Server Message Block 2.0 (SMB 2.0), Server Message Block 3.0 (SMB 3.0), Web-based Distributed Authoring and Versioning (WebDAV)
Network Standard
CIFS, FTP, iSCSI
Remote Management
HTTP, HTTPS, LDAP, SNMP
Expansion Bays
4 (total) / 4 (free) x hot-swap - 2.5" / 3.5"
Expansion Slots
1 (total) / 1 (free) x SO-DIMM 260-pin, 2 (total) / 2 (free) x M.2 2280
Interface Provided
2 x Ethernet 1000Base-T - RJ-45, 2 x USB 3.2 Gen 1 - Type A
Frequency
50/60 hertz
Power Consumption Operational
28.3 watt
Power Provided
90 watt
Required Voltage
AC 100-240 volt
Software Type
McAfee AntiVirus (Trial), Synology Central Management System
Built-in Devices
2 x fans, LED panel
Encryption
AES-NI
Storage Controller Interface
Serial ATA-600
Max Operating Temperature
40 degree Celsius
Min Operating Temperature
0 degree Celsius
Operating Humidity
5 - 95% RH
Operation Type
External power adapter
Sound Emission
19.8 dBA
Supported Devices
4
Compression Format
H.264, H.265
Features
92mm cooling fan, Citrix Ready, Power recovery, Reset button, Scheduled power on/off, Security lock slot (cable lock sold separately)
Image Resolution
1280x720, 1920x1080, 2048x1536, 2591x1944, 3840x2160
Installed Devices/Modules
0
IP Cameras Supported
40
Packaged Quantity
1
Security Slot Type
Kensington security slot
Cables
2 x network cable
Included Accessories
Accessory pack, Power cable
Height
16.6 centimetre
Width
19.9 centimetre
Depth
22.3 centimetre
Color Category
Black
Compliant Standards
BSMI, CCC, EAC, FCC, KC, RCM, RoHS, UKCA, VCCI
Service & Support Details
Limited warranty - 3 years
Limited Warranty
3 Year
Standby Power Consumption
8.45 watt
