Tech specs
Brand
Synology
Product Line
Synology Disk Station
Model
DS1522+
Manufacturer
Synology
Clock Speed
2.6 GHZ
Cores
Dual-Core
Max Turbo Speed
3.1 GHZ
Processor Brand
AMD
Processor Number
R1600
Processor Type
Ryzen Embedded
Processors Installed
1
Total Processor Supported
1
Max Memory Supported
32 GB
Memory Technology
DDR4 SDRAM
RAM Installed
8 GB
iSCSI support
iSCSI
Max Supported Capacity
108 TB
Network Storage Type
NAS server
Optical Drive Type
None
RAID Levels
JBOD, RAID 0, RAID 1, RAID 10, RAID 5, RAID 6
Total Storage Capacity
0 GB
Type
RAID
Compliant Standards
DLNA CERTIFIED
Data Link Protocols
Ethernet, Fast Ethernet, Gigabit Ethernet
Features
Access Control List (ACL) support, Advanced snapshot technology, Automated failover, B-tree file system (Btrfs), Cloud backup, Cloud sync, DNS server, EXT4 file system, File and folder-level data restoration, File self-healing, File station, Firewall protection, Flexible storage quota system, FTP server, High Availability, Inline compression, iSCSI LUN clone/snapshot, Let's Encrypt, Link Aggregation, Load balancing, Login auto block, NFS Kerberos authentication, ONVIF support, RADIUS Server, RAID migration, Shared folder encryption, SMB encryption, SSD read-write cache, SSD trim, Surveillance station, Synology Hybrid RAID, VPN Server, Wake On LAN (WOL), Wake on WAN (WOW)
Host Connectivity (compact list)
Gigabit Ethernet
Network Services Compatibility
Apple File Protocol (AFP), Calendaring Extensions to WebDAV (CalDAV), FTP, Microsoft Active Directory (AD), Network File System (NFS), Server Message Block (SMB), Web-based Distributed Authoring and Versioning (WebDAV)
Network Standard
CIFS, FTP, iSCSI, L2TP, OpenVPN, PPTP
Remote Management
SNMP, SSH, Telnet
Expansion Bays
5 (total) / 5 (free) x hot-swap - 2.5" / 3.5"
Expansion Slots
1 (total) / 1 (free) x PCI Express 3.0 x2, 2 (total) / 2 (free) x M.2 2280
Interface Provided
2 x eSATA, 2 x USB 3.2 Gen 1 - Type A, 4 x Ethernet 1000Base-T - RJ-45
Frequency
50/60 hertz
Power Consumption Operational
52.06 watt
Power Provided
120 watt
Storage Operating System
Synology DiskStation Manager
Built-in Devices
2 x fans
Encryption
AES-NI, SSL, TLS
Storage Controller Interface
Serial ATA-600
Max Operating Temperature
40 degree Celsius
Min Operating Temperature
0 degree Celsius
Operating Humidity
5 - 95% RH
Operation Type
External power adapter
Sound Emission
22.9 dBA
Supported Devices
5
Compression Format
H.264, H.265
Features
Scheduled power on/off, Security lock slot (cable lock sold separately)
Installed Devices/Modules
0
IP Cameras Supported
40
Packaged Quantity
1
Security Slot Type
Kensington security slot
Cables
2 x network cable
Included Accessories
Accessory pack
Height
16.6 centimetre
Weight
2.7 kilogram
Width
23 centimetre
Depth
22.3 centimetre
Color Category
Black
Compliant Standards
BSMI, CCC, EAC, FCC, KC, RCM, RoHS, UKCA, VCCI
Service & Support Details
Limited warranty - 3 years
Limited Warranty
3 Year
