Tech specs
Brand
Ricoh
Product Line
Ricoh fi
Model
7800
Manufacturer
Fujitsu Computer Products
Interfaces
USB 2.0 - Type B
Automatic Document Feeder Included
Automatic
Color Depth (External)
24-bit (16.7 million colors)
Compliant Standards
ISIS, TWAIN, WIA
Duplex Scanning
Yes
Duty Cycle
100000 scans per day
Grayscale Depth (External)
8-bit (256 gray levels)
Max Color Scan Speed (ppm)
110 pages per minute
Max H-Document Size
304.8 mm
Max H-Optical Resolution
600 dpi
Max Mono Scan Speed (ppm)
110 pages per minute
Max Scan Size
304.8 x 431.8 mm
Max V-Document Size
5588 mm
Max V-Optical Resolution
600 dpi
Scan Color
Color
Scan File Formats
BMP, JPEG, Multi-TIFF, PDF, TIFF
Scanner Features
Advanced DTC, Auto image rotation, Automatic color detection, Automatic Separation, Blank Page Detection, Color Dropout, Descreening, Deskew, Dither, Dynamic Threshold, Error Diffusion, Intelligent Multi-Feed Function (iMFF), Multi-Image Output, Punch Hole Removal, Remove Background, Simplified DTC, Split image control, Ultrasonic Multi Feed Detection
Scanner Interface Type
USB 2.0
Scanner Speed Details
110 ppm - landscape - A4 - 200 dpi, 110 ppm - landscape - A4 - 300 dpi, 180 ipm - portrait - A4 - 200 dpi, 180 ipm - portrait - A4 - 300 dpi, 220 ipm - duplex - landscape - A4 - 200 dpi, 220 ipm - duplex - landscape - A4 - 300 dpi, 90 ppm - portrait - A4 - 200 dpi, 90 ppm - portrait - A4 - 300 dpi
Supported Document Type
Business card, Envelope, Plain paper, Post card
Document Size Class
Other
Frequency
50/60 hertz
Power Consumption Operational
200 watt
Sleep-Mode Power Consumption
3.2 watt
Supported Document Size Details
ADF - up to 304.8 x 431.8 mm, Long document - up to 304.8 x 5588 mm
Type
External power adapter
Included Software
2D Barcode for PaperStream, Error Recovery Guide, PaperStream Capture, PaperStream IP, Scanner Central Admin, Software Operation Panel
ADF Capacity
500 Sheets
Form Factor
Desktop
Scanning Sensor Type
Dual CCD
Light Source
White LED array
Max Operating Temperature
35 degree Celsius
Min Operating Temperature
5 degree Celsius
Operating Humidity
20 - 80% (non-condensing)
Operating System Required
Microsoft Windows 7 (32/64 bits), Microsoft Windows Server 2008 (32/64-bits), Microsoft Windows Server 2008 R2 x64 Edition, Microsoft Windows Server 2012 R2 x64 Edition, Microsoft Windows Server 2012 x64 Edition, Microsoft Windows Server 2016 (64-bit), Microsoft Windows Server 2019 (64-bit), Windows 10 (32/64 bits), Windows 8.1 (32/64 bits)
Scanner Functionality
Document scanner
Packaged Quantity
1
System Requirements Details
Pentium 4 - 1.8 GHz - RAM 2 GB (USB)
Cables
1 x USB cable - 2 m
Height
46 centimetre
Weight
32 kilogram
Width
43 centimetre
Depth
31 centimetre
Color
Black, Gray
Color Category
Black, Gray
Compliant Standards
RoHS
ENERGY STAR Certified
Yes
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 90 days
Limited Warranty
90 Day
Standby Power Consumption
0.3 watt
