Tech specs
Brand
Ricoh
Product Line
Ricoh
Model
fi-7700
Manufacturer
Fujitsu Computer Products
Interfaces
USB 3.1 Gen 1 - Type B
Automatic Document Feeder Included
Automatic
Color Depth (External)
24-bit (16.7 million colors)
Compliant Standards
ISIS, TWAIN
Duplex Scanning
Yes
Duty Cycle
30000 scans per day
Grayscale Depth (External)
8-bit (256 gray levels)
Max Color Scan Speed (ppm)
100 pages per minute
Max H-Document Size
304.8 mm
Max H-Interpolated Resolution
1200 dpi
Max H-Optical Resolution
600 dpi
Max Mono Scan Speed (ppm)
100 pages per minute
Max Scan Size
ARCH B (304.8 x 457.2 mm)
Max V-Document Size
5588 mm
Max V-Optical Resolution
600 dpi
Scan Color
Color
Scanner Features
Advanced DTC, Automatic color detection, Barcode Detection, Blank Page Detection, Built-in LCD screen, Deskew, Dither, Dynamic Threshold, Error Diffusion, Image Emphasis, Long Paper Mode, Multi-Image Output, Paper Protection Function, Punch Hole Removal, RGB Color Dropout, Ultrasonic multifeed sensor
Scanner Interface Type
USB 3.1 Gen 1
Scanner Speed Details
0.6 sec/scan - landscape flatbed - A4 - 200 dpi, 0.6 sec/scan - landscape flatbed - A4 - 300 dpi, 0.9 sec/scan - portrait flatbed - A4 - 200 dpi, 0.9 sec/scan - portrait flatbed - A4 - 300 dpi, 100 ppm - landscape - A4 - 200 dpi, 100 ppm - landscape - A4 - 300 dpi, 160 ipm - duplex - portrait - A4 - 200 dpi, 160 ipm - duplex - portrait - A4 - 300 dpi, 200 ipm - duplex - landscape - A4 - 200 dpi, 200 ipm - duplex - landscape - A4 - 300 dpi, 80 ppm - portrait - A4 - 200 dpi, 80 ppm - portrait - A4 - 300 dpi
Supported Document Type
Bulk objects (such as books), Embossed card, Envelope, Plain paper, Plastic card
Document Size Class
Other
Interpolated Resolution
1200 dpi
Frequency
50/60 hertz
Power Consumption Operational
64 watt
Sleep-Mode Power Consumption
1.7 watt
Supported Document Size Details
ADF - up to 304.8 x 431.8 mm, Flatbed - up to ARCH B (304.8 x 457.2 mm), Long document - up to 304.8 x 5588 mm
Type
External power adapter
Included Software
2D Barcode for PaperStream, ABBYY FineReader for ScanSnap, Error Recovery Guide, PaperStream Capture, PaperStream IP, Scanner Central Admin, ScanSnap Manager, Software Operation Panel
ADF Capacity
300 Sheets
Form Factor
Desktop
Scanning Sensor Type
Triple CCD
Light Source
White LED array
Max Operating Temperature
35 degree Celsius
Min Operating Temperature
5 degree Celsius
Operating Humidity
20 - 80% (non-condensing)
Operating System Required
Microsoft Windows 7 (32/64 bits), Microsoft Windows Server 2008 (32/64-bits), Microsoft Windows Server 2008 R2 x64 Edition, Microsoft Windows Server 2012 R2 x64 Edition, Microsoft Windows Server 2012 x64 Edition, Microsoft Windows Server 2016 (64-bit), Windows 10 (32/64 bits), Windows 8.1 (32/64 bits)
Scanner Functionality
Document scanner
Packaged Quantity
1
System Requirements Details
Core i5 - 2.5 GHz - RAM 4 GB
Cables
1 x USB cable
Included Accessories
ADF paper chute, Stacker
Height
34.5 centimetre
Weight
35 kilogram
Width
70.6 centimetre
Depth
50 centimetre
Color Category
Black, White
Compliant Standards
RoHS
ENERGY STAR Certified
Yes
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 90 days - on-site
Limited Warranty
90 Day
Standby Power Consumption
0.35 watt
