Tech specs
Brand
Lenovo
Product Line
Lenovo Legion T5 26ARA8
Model
90UX
Manufacturer
Lenovo Topseller Desktops
Cache Level 2 Size (for systems with L3 only)
8 MB
Clock Speed
3.8 GHZ
Cores
8-core
Max Turbo Speed
5.3 GHZ
Processor Brand
AMD
Processor Number
7700
Processor Type
Ryzen 7
Processors Installed
1
Total Processor Supported
1
Available Memory Slots
2
Cache Memory
L3 cache
Cache Memory Installed
32 megabyte
Configuration Features
2 x 16 GB
Data Integrity Check
Non-ECC
Features
Dual channel memory architecture, Unbuffered
Max Memory Supported
32 GB
Memory Slots
4
Memory Speed
5200 megahertz
Memory Technology
DDR5 SDRAM, GDDR6 SDRAM
RAM Installed
32 GB
Rated Memory Speed
5600 megahertz
Drive Interface
PCI Express 4.0 x4
Drive Type
No optical drive
Hard Drive Capacity
1 TB
Hard Drive Features
NVM Express (NVMe)
Installed Quantity
1
Interface Class
PCI Express
Optical Drive Type
No optical drive, None
Optical Drive Type (2nd)
None
SSD Form Factor
M.2 2280
Storage (2nd)
None
Storage (3rd)
None
Storage (4th)
None
Storage Controller (2nd)
NVM Express
Storage Controller Type
Serial ATA
Type
None
Hard Drive Interface Type
SSD
Display Technology
None.
Graphics Controller Model
NVIDIA GeForce RTX 4060 / AMD Radeon Graphics
Graphics Processor Series
AMD Radeon, NVIDIA GeForce RTX
Multi-GPU Configuration
1 single GPU card / integrated GPU
Video Interfaces
DisplayPort, HDMI
Audio Input Type
None
Compliant Standards
High Definition Audio
Installed Size
8 GB
Interface Provided
1 x HDMI, 1 x headphones (1 top), 1 x LAN (1 rear), 1 x microphone (1 top), 1 x USB-C 3.2 Gen 2 (1 rear), 2 x USB 2.0 (2 rear), 2 x USB 3.2 Gen 2 (2 rear), 3 x audio connector, 3 x DisplayPort 1.4a, 4 x USB 3.2 Gen 1 (2 top, 2 rear)
Data Link Protocols
Bluetooth 5.3, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet Controllers
Realtek RTL8125BG
Features
Dual stream (2x2)
Host Interface
M.2 Card
Wireless LAN
802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth 5.3
Wireless LAN Supported
Yes
Built-in Devices
1 x rear ARGB fan, 150W 120 mm fan with ARGB lighting air cooler, 2 x front ARGB fans, Internal ambient lighting, Legion Wordmark lighting, Transparent side cover
Chipset Type
AMD B650
Efficiency
85%
Embedded Security
Firmware Trusted Platform Module (TPM 2.0) Security Chip
Form Factor
Tower
Form Factor (RAM)
DIMM 288-pin
Storage Controller Interface
Serial ATA-600
Input Device Type
Keyboard, Mouse
Interface
USB
Max Operating Temperature
35 degree Celsius
Min Operating Temperature
5 degree Celsius
Mouse Name
Lenovo Calliope Mouse
Operating Humidity
20 - 80%
Controllers Included
1
Country
United States
Printer Product Type
None
Keyboard Localization
English
Keyboard Name
Lenovo Calliope Keyboard
Keys Layout
QWERTY
Localization
English
Manufacturer Form Factor
Tower
Packaged Quantity
1
Product Type
Personal computer
Expansion Bays
2 (total) / 2 (free) x internal 3.5"
Slots
1 (total) / 0 (free) x M.2 Card (for WLAN), 1 (total) / 0 (free) x PCIe 4.0 x16, 1 (total) / 1 (free) x PCIe 3.0 x4, 3 (total) / 2 (free) x M.2 Card (for SSD)
Bundled Services
3 Year Legion Ultimate Support
Operating System
Windows 11 Pro
Operating System Edition
Windows 11 Pro
Operating System Language
English
Operating System Platform
Windows
Frequency
50/60 hertz
Power Device Type
Power supply
Power Provided
500 watt
Required Voltage
AC 100-240 volt
Included Accessories
Carrying handle, M.2 SSD DECO MYLAR heatsink, PCH heatsink
Compliant Standards
Energy-Related Products (ErP) Lot 3, RoHS
ENERGY STAR Certified
Yes
Energy Star Version
8.0
EPEAT Compliant
No
TCO Certified
No
Color
Storm gray
Color Category
Gray
Height
42.59 centimetre
Weight
14 kilogram
Width
20.5 centimetre
Depth
39.69 centimetre
On-Site Warranty
On-site
Service & Support Details
Base warranty - 1 year - carry-in, Extended warranty - 3 years - on-site
Limited Warranty
3 Year
