Tech specs
Brand
Cisco Meraki
Product Line
Cisco Meraki Cloud Managed
Model
MS125-24P
Manufacturer
Meraki
Compliant Standards
IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at
Features
Access Control List (ACL) support, Auto-negotiation, Auto-uplink (auto MDI/MDI-X), Broadcast Storm Control, Cisco Discovery Protocol, Crossover detection, DHCP client, DHCP snooping, DSCP to CoS Mutation, E-mail alert, Fanless, Firmware upgradable, Flow control, IGMP snooping, Link Aggregation Control Protocol (LACP), Port mirroring, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, Role-Based Access Control (RBAC), Security lock slot (cable lock sold separately), Single Sign-On (SSO) support, SMS alert, Spanning Tree Protocol (STP) support, STP BPDU Guard, STP Root Guard, Syslog support, VLAN support, Zero-touch provisioning (ZTP)
Form Factor (Hubs & Switches)
Desktop, Wall-mountable
Jumbo Frame Support
9578 bytes
MAC Address Table Size
16000 entries
Manageable
Yes
PoE Budget
370 watt
Ports
24
Power Over Ethernet (PoE)
PoE
Product Type
Switch
Remote Management
SNMP
Subcategory
Network hubs and switches
Switching Type
10 Gigabit Ethernet
Interface Provided
24 x 1000Base-T RJ-45 PoE, 4 x 10Gbit LAN SFP+
Port Quantity
24
Port Type
10/100/1000 (PoE)
Ports Type (2nd)
10 Gigabit SFP+
Frequency
47 - 63 hertz
Power Consumption Operational
426.1 watt
Max Operating Temperature
40 degree Celsius
Min Operating Temperature
0 degree Celsius
MTBF
294,713 Hours
Operating Humidity
5 - 95% (non-condensing)
Authentication Method
RADIUS
Capacity
MAC forwarding entries: 16000, VLANs supported: 4094
Device Type
Internal power supply
Packaged Quantity
1
Performance
Forwarding rate: 95.23 Mpps, Switching capacity: 128 Gbps
Ports (2nd) Quantity
4
Rack Mounting Kit
Included
Height
4.4 centimetre
Height (Rack Units)
1
Weight
4.2 kilogram
Width
44 centimetre
Depth
25 centimetre
Color Category
White
Compliant Standards
CSA, FCC, IC, RCM, RoHS
Service & Support Details
Limited warranty - advance parts replacement - lifetime - response time: next business day
Limited Warranty
Limited Lifetime
