Tech specs
Brand
Axis
Product Line
AXIS
Model
M3216-LVE
Manufacturer
Axis Communications
Flash Memory Installed
8192 megabyte
Memory Cards Supported
microSD Card, microSDHC Card, microSDXC Card
RAM Installed
1024 megabyte
Network Interface
Ethernet 10Base-T/100Base-TX
Protocols
ARP, Bonjour, CDP, CIFS, DDNS, DHCP, DNS, EAP, FTP, HTTP, HTTPS, ICMP, IGMP, IGMPv2, IGMPv3, IPv4, IPv6, LLDP, MQTT, NTP, QOS, RTCP, RTP, RTSP, SFTP, SIP, SMB, SMTP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, SRTP, SSH, Syslog, TCP/IP, TLS, UDP/IP, UPnP, USGv6, Zeroconf
Connectivity Technology
Wired
Ports
Audio line-in/microphone - 3.5 mm jack, Digital input/output - terminal block, LAN/power - RJ-45
Image Sensor Size
1/2.7"
Image Sensor Type
PS RGB CMOS
Tilt
-10 to +80
Audio Formats
AAC, G.711, LPCM, OPUS
Audio Support
Yes
Audio Support Features
Built-in microphone, Two-way audio via edge-to-edge technology
Camera Mechanical Design
Fixed
Digital Video Capture Resolution
160 x 120, 160 x 90, 2304 x 1728, 2688 x 1512
Max Frame Rate
60 frames per second
Max Digital Video Resolution
2688 x 1512
Motion Detection
Yes
Panning Range (degree)
-190 to +190
Shutter Speed (Max)
1/50000 second (time unit)
Shutter Speed (Min)
1/5 second (time unit)
Camera Type
Network surveillance camera
Night Vision
Yes
Low Voltage Power
DC 12 V / PoE
Power Consumption Operational
4.8 watt
Software Type
AXIS Camera Station, AXIS Companion, Windows decoder 1-user license
Angular Field of View (H, Max, Degree)
102
Angular Field of View (V, Max, Degree)
73
Camera Iris
Fixed iris
Focal Length Control
Fixed focal
Form Factor
Dome
Indoor/Outdoor
Outdoor
Infrared Distance
30 metre
Lens Aperture
F/2.0
Max Operating Temperature
50 degree Celsius
Min Focal Length
2.9 millimetre
Min Operating Temperature
-40 degree Celsius
Minimum Illumination
0 lux - B&W - F2.0 - 50 IRE - infrared LEDs on, 0.16 lux - color - F2.0 - 50 IRE
Operating Humidity
5 - 95% RH (non-condensing)
Protection
Vandal / waterproof
Sensor Size (metric)
9.4 mm (1/2.7")
Total Pixels
4,000,000 pixels
Video Formats
H.264, H.265, MJPEG, MPEG-4 Part 10, MPEG-H Part 2
Video Input
Color
Alarm Input Quantity
1
Alarm Output Quantity
1
Features
180° image rotation, 270° image rotation, 90° image rotation, Access Control, Adaptive Bitrate (ABR), Axis device ID, Axis Edge Vault, Barrel distortion correction, Brightness control, Brute force delay protection, Centralized certificate management, Compression, Contrast control, Day shift, Deep learning processing unit (DLPU), Defogging, Digest authentication, Digital PTZ function, Dynamic text overlay, E-mail alerts, Exposure mode, Exposure zone, Forensic WDR, HTTPs encryption, Image mirror, Image overlay, Infrared-cut filter, IP address filtering, Multi-Bitrate (MBR), Network speaker pairing, Night shift, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, Password protection, Plastic housing, Polygon privacy mask, Saturation control, Secure Boot, Secure keystore, Sharpness control, Signed firmware, Sunshield, Tone mapping, User access log, Variable Bit Rate (VBR), Video streaming indicator, VoIP support, White balance, Wide Dynamic Range (WDR), Zipstream technology
Localization
Chinese (Simplified), Chinese (Traditional), English, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish
Packaged Quantity
1
Included Accessories
Cable gaskets, Connector guard, Drill hole template, Resitorx TR20 screw bit, Terminal block connectors, Weathershield
Height
10.2 centimetre
Weight
791 gram
Width
14.9 centimetre
Depth
14.9 centimetre
Color
NCS S 1002-B, White
Color Category
White
Compliant Standards
AS/NZS CISPR 32 Class A, EAL 4, EN 55032 Class A, EN 61000-6-1, EN 61000-6-2, FCC Part 15 B Class A, ICES-3(A)/NMB-3(A), IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78, IEC 62471, IEC/EN 60529 IP66, IEC/EN 62262 IK10, IEC/EN/UL 60950-22, IEC/EN/UL 62368-1, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, KCC KN35, KN32 Class A, NEMA TS-2 (2.2.7-2.2.9), NEMA Type 4X, NIST SP500-267, RCM, VCCI Class A
Service & Support Details
Limited warranty - 5 years
Limited Warranty
5 Year
