Tech specs
Brand
Cisco
Product Line
Cisco Industrial Ethernet
Model
2000 IP67 Series
Manufacturer
Cisco Systems
Flash Memory Installed
64 megabyte
RAM Installed
256 megabyte
Compliant Standards
IEEE 1588v2, IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Features
ARP support, BOOTP support, Broadcast Storm Control, Cisco Fast EtherChannel, Class of Service (CoS), DHCP relay, DHCP server, DHCP snooping, DiffServ support, Dynamic ARP Inspection (DAI), IGMP filtering, IGMP snooping, IPv6 support, LLDP support, MAC address filtering, MAC Address Notification, Multicast Storm Control, Multiple Spanning Tree Protocol (MSTP) support, NAT support, Port Security, Precision Time Protocol (PTP), PROFINET v2, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, Remote Switch Port Analyzer (RSPAN), Spanning Tree Protocol (STP) support, Syslog support, Trivial File Transfer Protocol (TFTP) support, Unicast Storm Control, Uni-Directional Link Detection (UDLD), Virtual Route Forwarding-Lite (VRF-Lite), VLAN support
Form Factor (Hubs & Switches)
Wall-mountable
MAC Address Table Size
8K entries
Manageable
Yes
Ports
8
Power Over Ethernet (PoE)
PoE+
Product Type
Switch
Remote Management
RMON, SNMP 1, SNMP 2, SNMP 3, SSH, Telnet
Routing Protocol
BGP, OSPF, RIP, Static IPv4 routing, Static IPv6 routing
Subcategory
Network hubs and switches
Switching Type
Fast Ethernet
Expansion Slots
1 (total) / 1 (free) x SD Memory Card
Interface Provided
1 x console M12, 2 x 1000Base-T M12 uplink, 8 x 100Base-TX M12 PoE+
Port Quantity
8
Port Type
10/100 (PoE+)
Ports Type (2nd)
10/100/1000
Power Consumption Operational
73 watt
Software Type
Cisco IOS LAN Enhanced
Max Operating Temperature
60 degree Celsius
Max Storage Temperature
85 degree Celsius
Min Operating Temperature
-40 degree Celsius
Min Storage Temperature
-40 degree Celsius
MTBF
374,052 Hours
Operating Humidity
5 - 95% (non-condensing)
Authentication Method
RADIUS, Secure Shell (SSH), TACACS+
Capacity
IGMP groups: 255, VLANs supported: 1005
Packaged Quantity
1
Performance
Forwarding performance (64-byte packet size): 6.5 Mpps
Ports (2nd) Quantity
2
Height
24.17 centimetre
Weight
3.26 kilogram
Width
23.67 centimetre
Depth
9.9 centimetre
Color Category
White
Compliant Standards
BSMI CNS 13438 Class A, CISPR 11 class A, CISPR 22 Class A, CISPR 24, CSA 22.2 No. 142, EN 50121-3-2, EN 50121-4, EN 55011, EN 60945, EN 60950-1, EN 61000-4-10, EN 61000-4-2, EN 61000-4-29, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-9, EN 61000-6-1, EN 61000-6-2, EN 61000-6-4, EN 61131-2, EN 61326, EN50155, EN55022 Class A, EN55024, ICES-003 Class A, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-30, IEC 60068-2-31, IEC 60068-2-32, IEC 60068-2-52, IEC 60068-2-6, IEC 60068-2-64, IEC 60950-1, IEC 61850-3, IP67, NEMA TS-2, NEMA Type 4, UL 508, UL 60950-1, VCCI Class A
Service & Support Details
Limited warranty - 5 years
Limited Warranty
5-year warranty
